The new G10 Creamback packs everything guitar players love about Creamback speakers into a 10-inch format. Hand-built in the UK using the same production methods and materials developed for the 12-inch models, the G10 Creamback uses a ceramic magnet and a 1.75-inch voice coil to deliver 45-watt power handling. With all the punch and dynamics typical of a 10, its overall tone is warm, expressive, detailed and well-balanced.

:

Nominal diameter 10", 254mm
Power rating 45W
Nominal impedance Available 8Ω or 16Ω
Sensitivity 96dB
Chassis type Pressed steel
Voice coil diameter 1.75", 44.5mm
Voice coil material Round copper
Magnet type Ceramic
Magnet weight 14oz
Frequency range 95-5500Hz
Resonance frequency, Fs 98Hz
DC resistance, Re Available 6.4Ω or 12.05Ω

Mounting Information
Cut-out diameter 9.0", 229mm
Diameter 10.0", 254mm
Magnet structure diameter 4.9", 124mm
Mounting slot dimensions 0.25 x 0.43", 6.5 x 11mm Ø
Mounting slot PCD 9.6", 245mm
Number of mounting slots 8
Overall depth 4.0", 102mm
Unit weight 3.5lb, 1.6kg
